| Steel | Diameter | Proof | Yield | Tensile | |
| Low Carbon Steel | S020------- | 1/4" - 3/4" 3/4" - 1 1/2" |
55,000 33,000 |
57,000 36,000 |
57,000 36,000 |
| ASTM A193 B7 | SB70------- | 1/4" - 2 1/2" 2 1/2" - 4" 4" - 7" |
105,000
95,000 75,000 |
125,000 115,000 100,000 |
|
| ASTM A320 L7 | SL70------- | 1/4" - 2 1/2" | --- | 105,000 | 125,000 |
| ASTM A193 B16 | SB16------- | 1/4" - 2 1/2" 2 1/2" - 4" 4" - 7" |
105,000 95,000 85,000 |
125,000
115,000 100,000 |
| Stainless | |||||
| 304/18-8 Stainless Steel | S188------- | 1/4" and larger | --- | 30,000 | 75,000 |
| 316 Stainless Steel | S316------- | 1/4" and larger | --- | 30,000 | 75,000 |
| ASTM A193 B8 | SB80------- | 1/4" and larger | --- | 30,000 | 75,000 |
| ASTM A193 B8M | SB8M------- | 1/4" and larger | --- | 30,000 | 75,000 |
Disclaimer: The dimensions listed are for reference only. Sizes not listed may be available off the shelf or can be manufactured to customer requirements.
